Center Conductor

Material

SPCW ( : SCCS )

SPCW ( : SCCS )

Structure

( 7/0.0040 inch )

( 7/0.0040 inch )

Diameter

0.31 mm

0.0120 inch

0.31 mm

0.0120 inch

0.51 mm

Dielectric

Solid PTFE

0.84 mm

0.033 inch

1.60 mm

0.063 inch

1.52 mm

Shield

SC

Silver Plated Copper Wire

1.33 mm

0.052 inch

2.00 mm

0.079 inch

2.00 mm

TC

Tin Plated Copper Wire

1.33 mm

0.052 inch

2.00 mm

0.079 inch

2.00 mm

Jacket

FEP

1.80 mm

0.071 inch

2.54 mm

0.100 inch

2.50 mm

Weight

8.4 Kg/Km

2.6 Kg/1000ft

14.8 Kg/Km

4.5 Kg/1000ft

16.0 Kg/Km

Temperature Range (℃)

-55 ~ +200℃

-55 ~ +200℃

Minimum Bend Radius

10.2 mm

0.4 inch

12.7 mm

0.5 inch

12.7mm

Impedance (Ohms)

50 Ω

75Ω

Capacitance (pF/ft.)

96.5 pF/M

29.4 pF/ft

64.0 pF/M

19.5 pF/ft

96.5 pF/M

Velocity of propagation ( % )

70 %

70 %
